DEM 20485 SYH-LY

LCD dot matrix modules

• dot matrix modules with 4 lines and 20 characters
​• high contrast LCD-STN display
• LED backlight
• characters: schwarz
• by Display Elektronik
• interface for 4- or 8-Bit data bus
• supply voltage: 5V
• operating temperature range: -20 to +70°C

DEM 20485 SYH-LY View larger

DEM 20485 SYH-LY

8267 DEM 20485 SYH-LY DEM20485SYH-LY DEM20485SYH-LY LCD dot matrix modules. • dot matrix modules with 4 lines and 20 characters​• high contrast LCD-STN display• LED backlight• characters: schwarz• by Display Elektronik• interface for 4- or 8-Bit data bus• supply voltage: 5V• operating temperature range: -20 to +70°C

Data sheet

manufacturer's name DEM20485SYH-LY
dimensions [mm] 98x60x14,5
lines 4
characters 20
background yellow/green
illumination yellow
field of view [mm] 76,3x25
character size [mm] 2,95x4,75


Data Sheet

14,89 €

stock: 532
