EA W404B-NLW

LCD dot matrix modules

• dot matrix modules with 4 lines and 40 characters
• high contrast LCD-STN display, COG
• backlight
• characters: white
• by Electronic Assembly
• interface for 4- or 8-Bit data bus
• supply voltage: 5V
• operating temperature range: -20 to +70°C

EAW404B-NLW, 4 lines, 40 characters

EA W404B-NLW

32494 EA W404B-NLW EAW404B-NLW EAW404B-NLW LCD dot matrix modules. • dot matrix modules with 4 lines and 40 characters• high contrast LCD-STN display, COG• backlight• characters: white• by Electronic Assembly• interface for 4- or 8-Bit data bus• supply voltage: 5V• operating temperature range: -20 to +70°C

Specifications

manufacturer
Manufacturer's name EAW404B-NLW
Character size [mm] 2,78x4,89
Background blue
Illumination white
Lines 4
Characters 40
Field of view [mm] 147x29,5
Dimensions [mm] 190x54x13,6
Data Sheet

Unit price

94,09 €

Stock: 7
Further delivery:
CW 06/2026
