HD4825-10

Crydom solid state relay series CW48 and HD48

  • electronic solid state relays for AC voltages
  • in a hockey puck housing
  • partly with a fingerproof cover (CW_)
  • random switching types (HD_-10) for inductive loads as well as zero-voltage switching versions (CW_/HD_) for capacitive and resistive loads
  • isolation voltage: 4kV
  • operating temperature: -40 to +80°C
HD4825-10, Crydom solid state relays, 10 to 125A, 660V, thyristor output, CW48 and HD48 series

HD4825-10

238293 HD4825-10 HD4825-10 Crydom solid state relay series CW48 and HD48. electronic solid state relays for AC voltages in a hockey puck housing partly with a fingerproof cover (CW_) random switching types (HD_-10) for inductive loads as well as zero-voltage switching versions (CW_/HD_) for capacitive and resistive loads isolation voltage: 4kV operating temperature: -40 to +80°C

Specifications

manufacturer
Manufacturer's name HD4825-10
Non repetitive surge peak on-state current [A] 250
Switch positions instantaneou...
Max. off-state output voltage [V] 1200
Forward current, max. [A] 25
Control voltage [V] 4...32
Zero-Voltage Switching [V] 48...530
Data Sheet

Unit price

69,79 €

Stock: 20
Further delivery:
CW 08/2026
