PF 240D 25

electronic solid state relays, 25A

• SIP/SIL housing
• for alternating voltage
• thyristor output
• series PF by crydom
• 4 kV insulation voltage
• zero crossing circuit
• integrated heatsink
• operating temperature:up -30 to +80°C

PF240D25, Crydom solid state relays, 25A, 280 to 660V, thyristor output, SIL housing, PF and SPF series View larger

PF 240D 25

26626 PF 240D 25 PF240D25 PF240D25 electronic solid state relays, 25A. • SIP/SIL housing• for alternating voltage• thyristor output• series PF by crydom• 4 kV insulation voltage• zero crossing circuit• integrated heatsink• operating temperature:up -30 to +80°C

Data sheet

manufacturer
manufacturer's name PF240D25
non repetitive surge peak on-state current [A] 250
switch positions zero-voltage switching
max. off-state output voltage [V] 600
forward current, max. [A] 25
control voltage [V] 3...15
load voltage [V] 12...280

Download

Data Sheet

24,89 €

stock: 0
Next incoming:
CW:05/2022
42 pieces
