> Passive elements>Relays>Electromechanical relays>DIN rail sockets and modules for relays by Finder>99.80.0 6-24V

Manufacturers

99.80.0 6-24V

DIN rail sockets and accessories

• no reduction in the insulation class resp. the creepage and clearance by plastic retaining clips
• relays are easily replaced
• modules are placed easily and safely (proper polarity alignment) into the socket
• rated voltage: 250V AC
• rated current: 10A
• insulation resistance: 103MΩ
• insulation voltage: 2kV
• type of protection: IP20
• housing material: PA66
• contacts: CuZn33, nickel-plated

• LED display with varistor (6...24V AC/DC)

99.80.0 6-24V

99.80.0 6-24V

11920 99.80.0 6-24V 99.80.0.024.98 99.80.0.024.98 DIN rail sockets and accessories. • no reduction in the insulation class resp. the creepage and clearance by plastic retaining clips• relays are easily replaced• modules are placed easily and safely (proper polarity alignment) into the socket• rated voltage: 250V AC• rated current: 10A• insulation resistance: 103MΩ• insulation voltage: 2kV• type of protection: IP20• housing material: PA66• contacts: CuZn33, nickel-plated• LED display with varistor (6...24V AC/DC)

Specifications

manufacturer
Manufacturer's name 99.80.0.024.98
Data Sheet

Unit price

4,59 €

Stock: 109
Further delivery:
CW 35/2024

Minimum order quantity 1 to 9 units or multiples of 10 plus 0 to 9 .
