DS 08

ECE DIL switch series EDG and EDS

  • DIL switches with gold-plated (EDG_S) or tinned (EDG_S33) contacts
  • fluxproof types
  • with a blue insulator (UL94V-0)
  • switching capability of 2000 operations
  • maximal operating force: 800g
  • operating temperature: -25 to +70°C
  • spacing between rows: 7,62mm
  • pitch: 2,54mm

DS 08

13204 DS 08 EDG108S EDG108S ECE DIL switch series EDG and EDS. DIL switches with gold-plated (EDG_S) or tinned (EDG_S33) contacts fluxproof types with a blue insulator (UL94V-0) switching capability of 2000 operations maximal operating force: 800g operating temperature: -25 to +70°C spacing between rows: 7,62mm pitch: 2,54mm

Specifications

manufacturer
Manufacturer's name EDG108S
Switch 8
A [mm] 21,7
Data Sheet

Unit price

5,09 €

Volume discounts

Quantity Unit price
23 + 0,891 €

Stock: 0
Next incoming goods:
CW 23/2024
997 units


Further delivery:
CW 30/2024
