EA10731K2401

EDACPOWER desktop power supply series EA1073

Desktop switching power supplies with 60W and a universal input. These devices are suitable for indoor applications and are protected against short circuit, overload as well as overvoltage. They comply with EN62368-1, EN55032 class B and energy efficiency Level VI (DoE). We offer the following types of this EDACPOWER series: EA10731J1201, EA10731J1501, EA10731K2401 and EA10731M4801.

  • single output
  • output: 60W
  • input voltage: 90 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 120A
  • cable length: 1,2m
  • input plug: C14
  • output plug, coax: 2,1x5,5mm
  • dimensions: 105,5x46x28mm
  • operating temperature: 0 to +40°C
EA10731K(T01), EDACPOWER desktop switching power supplies, 60W, energy efficiency Level VI, EA1073 series

EA10731K2401

233991 EA10731K2401 EA10731K(T01) EA10731K(T01) EDACPOWER desktop power supply series EA1073. Desktop switching power supplies with 60W and a universal input. These devices are suitable for indoor applications and are protected against short circuit, overload as well as overvoltage. They comply with EN62368-1, EN55032 class B and energy efficiency Level VI (DoE). We offer the following types of this EDACPOWER series: EA10731J1201, EA10731J1501, EA10731K2401 and EA10731M4801. single output output: 60W input voltage: 90 to 264V AC (47 to 63Hz) maximal input inrush current: 120A cable length: 1,2m input plug: C14 output plug, coax: 2,1x5,5mm dimensions: 105,5x46x28mm operating temperature: 0 to +40°C

Specifications

manufacturer
Manufacturer's name EA10731K(T01)
Output voltage [V] 24
Efficiency [%] 89
Output current [A] 2,5
Output voltage tolerance: [%] +5/-5
Output power [W] 60
Ripple [mVp-p] 360
Data Sheet

Unit price

14,19 €

Stock: 927
Further delivery:
CW 36/2024
