MUGE 46 schwarz

universal enclosures

• two half "lap-joint" construction shells make up this enclosure
• MUGE 46 and MUGE 47 can be combined as required
• both enclosure shells are connected by a snap-in lock
• guide rails and receivers for PC boards are available on the shell halves

• total height of MUGE 46 + MUGE 46: 29 mm
• total height of MUGE 46 + MUGE 47: 40 mm

MUGE 46 black

MUGE 46 schwarz

17045 MUGE 46 schwarz MUGE 46 schwarz universal enclosures. • two half "lap-joint" construction shells make up this enclosure• MUGE 46 and MUGE 47 can be combined as required• both enclosure shells are connected by a snap-in lock• guide rails and receivers for PC boards are available on the shell halves• total height of MUGE 46 + MUGE 46: 29 mm• total height of MUGE 46 + MUGE 47: 40 mm

Specifications

Outside dimensions [mm] 123x70x14,5
Inside dimensions [mm] 118x64x12

Unit price

0,567 €

Stock: 1
Next incoming goods:
CW 24/2024
4660 units

Further delivery:
CW 27/2024

Minimum order quantity 1 unit or multiples of 10 plus 0 to 1 .
