Manufacturers

GMB 100 V 10000 µF

FTCAP capacitor series GMB

  • radial type electrolytic capacitors
  • with screw terminals for stud mounting
  • all internal contacts are welded
  • operating temperature: -40 to +85°C
  • capacitance tolerance: ±20%
  • bulk

Matching GMA clamps

GMB 100 V 10000 µF

109773 GMB 100 V 10000 µF GMB10310040070 GMB10310040070 FTCAP capacitor series GMB. radial type electrolytic capacitors with screw terminals for stud mounting all internal contacts are welded  operating temperature: -40 to +85°C capacitance tolerance: ±20% bulk Matching GMA clamps

Specifications

manufacturer
Manufacturer's name GMB10310040070
Nominal voltage [V DC] 100
Reverse current [A] 9,4
Impedance [mΩ] 16
Rated capacitance [µF] 10.000
Loss factor at 100Hz, 20°C [%] 10
D x L [mm] 40x70
Data Sheet

Unit price

24,39 €

Stock: 116
Further delivery:
CW 05/2025
