87 H 301X1C 02

• plug housing for application in crimp pin contacts
• pitch: 3mm
• housing material: nylon 6.6
• flammability class: UL94V-0
• current rating, max.: 5A
• rated voltage: 250V AC/DC
• temperature range: -25...+105°C

87 H 301X1C 02

33962 87 H 301X1C 02 87 H 301X1C 02 • plug housing for application in crimp pin contacts• pitch: 3mm• housing material: nylon 6.6• flammability class: UL94V-0• current rating, max.: 5A• rated voltage: 250V AC/DC• temperature range: -25...+105°C

Discontinued items. Only remainder of stock available.

Specifications

Number of poles 1x2
A [mm] 3
Width [mm] 6,85
Data Sheet

Unit price

0,10 €

Stock: 1
