> Passive elements>Transformers>PCB transformers>Hahn PCB transformers, 30VA, EI 66>BV EI 662 1092

Manufacturers

BV EI 662 1092

Hahn PCB transformers

Transformers with 30VA and an EI66 core. These devices are  not short circuit proof and suitable for PCB mounting. They comply with temperature resistance class Ta 70/B and are vacuum casted. We offer the following types of this Hahn series: BV EI 6624039, BV EI 6624042, and BV EI 6624043.

  • core: EI 66
  • output: 30VA
  • input voltage: 230V AC (50/60Hz)
  • temperature class: Ta 70/B
  • permissible overtemperature: 50K
  • test voltage: 4kV/50Hz
BVEI6621092, Hahn PCB transformers, 30VA, EI 66

BV EI 662 1092

249838 BV EI 662 1092 BVEI6621092 BVEI6621092 Hahn PCB transformers. Transformers with 30VA and an EI66 core. These devices are  not short circuit proof and suitable for PCB mounting. They comply with temperature resistance class Ta 70/B and are vacuum casted. We offer the following types of this Hahn series: BV EI 6624039, BV EI 6624042, and BV EI 6624043. core: EI 66 output: 30VA input voltage: 230V AC (50/60Hz) temperature class: Ta 70/B permissible overtemperature: 50K test voltage: 4kV/50Hz

Specifications

manufacturer
Manufacturer's name BVEI6621092
Secondary voltage [V] 12
Secondary current [A] 2,75
Data Sheet

Unit price

27,39 €

Stock: 0
Further delivery:
CW 01/2026

Minimum order quantity 9 units or
multiples of 9.
