BV EI 601 1044

print transformers 20VA by Hahn

* output, max. (Ta 70/B): 20VA
* core: EI60
* non short-circuit proof
* winding of double coated copper wire for better insulation, vacuum casted, two chambers
* connections for PCB use
* temperature resistance class: Ta 70/B
* end temperature in standard use: 120°C
* permissible overtemperature: 50K
* primary voltage (50/60Hz): 230V AC
* test voltage: 4kV/50Hz
* no-load voltage (according to VDE 0570): 1.5 x UN sec.

BVEI6011044, Hahn PCB transformers, 20VA, EI 60

BV EI 601 1044

249836 BV EI 601 1044 BVEI6011044 BVEI6011044 print transformers 20VA by Hahn. * output, max. (Ta 70/B): 20VA* core: EI60* non short-circuit proof * winding of double coated copper wire for better insulation, vacuum casted, two chambers* connections for PCB use* temperature resistance class: Ta 70/B* end temperature in standard use: 120°C* permissible overtemperature: 50K* primary voltage (50/60Hz): 230V AC* test voltage: 4kV/50Hz* no-load voltage (according to VDE 0570): 1.5 x UN sec.

Specifications

manufacturer
Manufacturer's name BVEI6011044
Secondary voltage [V] 2x15
Secondary current [A] 2x0,666
Data Sheet

Unit price

22,99 €

Stock: 0
Further delivery:
CW 01/2026

Minimum order quantity 10 units or
multiples of 10.
