> Passive elements>Transformers>PCB transformers>Hahn PCB transformers, 2,3VA, EI 30>BV EI 305 2800

Manufacturers

BV EI 305 2800

Hahn PCB transformers

Transformers with 2,3VA and an EI30 core. These devices are short circit proof and vacuum casted. They are suitable for PCB mounting and comply with temperature resistance class Ta 40/F. We offer the following types of this Hahn series: BV EI 305 2800 and BV EI 305 2866.

  • core: EI 30
  • output: 2,3VA
  • input voltage: 230V AC (50/60Hz)
  • temperature class: Ta 40/F
  • maximal end temperature (short circuit): 190°C
  • maximal end temperature: 140°C
  • permissible overtemperature: 100K
  • test voltage: 4kV
BV EI 305_

BV EI 305 2800

111652 BV EI 305 2800 BVEI3052800 BVEI3052800 Hahn PCB transformers. Transformers with 2,3VA and an EI30 core. These devices are short circit proof and vacuum casted. They are suitable for PCB mounting and comply with temperature resistance class Ta 40/F. We offer the following types of this Hahn series: BV EI 305 2800 and BV EI 305 2866. core: EI 30 output: 2,3VA input voltage: 230V AC (50/60Hz) temperature class: Ta 40/F maximal end temperature (short circuit): 190°C maximal end temperature: 140°C permissible overtemperature: 100K test voltage: 4kV

Specifications

manufacturer
Manufacturer's name BVEI3052800
Secondary voltage [V] 12
Secondary current [A] 0,192
Data Sheet

Unit price

2,69 €

Stock: 165
Further delivery:
CW 20/2024

Minimum order quantity 5 units or
multiples of 5.
