1550E

Hammond diecast enclosure series 1550

Rugged, diecast aluminium enclosures with a natural finish or a black powder coating. These housings are IP54 rated (1550_) without a gasket and IP66 rated (1550W_) with a gasket. They have a lap joint construction which guarantees protection against dust and splashing water. A low side wall draft angle (≤2°) allows easy mounting of printed circuit boards. The cover is secured with four M3.5x0.6x12mm Phillips stainless steel machine screws.

1550E

114699 1550E 1550E Hammond diecast enclosure series 1550. Rugged, diecast aluminium enclosures with a natural finish or a black powder coating. These housings are IP54 rated (1550_) without a gasket and IP66 rated (1550W_) with a gasket. They have a lap joint construction which guarantees protection against dust and splashing water. A low side wall draft angle (≤2°) allows easy mounting of printed circuit boards. The cover is secured with four M3.5x0.6x12mm Phillips stainless steel machine screws.

Specifications

manufacturer
Manufacturer's name 1550E
Colour unpainted
Height [mm] 55,1
Width [mm] 121
Length [mm] 172
Data Sheet

Unit price

13,99 €

Stock: 17
Further delivery:
CW 16/2024
