1550FBK

Hammond diecast enclosure series 1550

Rugged, diecast aluminium enclosures with a natural finish or a black powder coating. These housings are IP54 rated (1550_) without a gasket and IP66 rated (1550W_) with a gasket. They have a lap joint construction which guarantees protection against dust and splashing water. A low side wall draft angle (≤2°) allows easy mounting of printed circuit boards. The cover is secured with four M3.5x0.6x12mm Phillips stainless steel machine screws.

1550FBK, Hammond diecast enclosures, aluminium, 1550 series

1550FBK

114702 1550FBK 1550FBK Hammond diecast enclosure series 1550. Rugged, diecast aluminium enclosures with a natural finish or a black powder coating. These housings are IP54 rated (1550_) without a gasket and IP66 rated (1550W_) with a gasket. They have a lap joint construction which guarantees protection against dust and splashing water. A low side wall draft angle (≤2°) allows easy mounting of printed circuit boards. The cover is secured with four M3.5x0.6x12mm Phillips stainless steel machine screws.

Specifications

manufacturer
Manufacturer's name 1550FBK
Colour black
Height [mm] 105,1
Width [mm] 121
Length [mm] 171
Data Sheet

Unit price

24,89 €

Stock: 5
Further delivery:
CW 19/2024
