MKT RM15 630V 0,047µF

pitch: 10...27,5mm

* loose
* tolerance: 10%
* pitch: 10...27.5mm
* dielectric polyester film
* aluminium layer plates deposited by evaporation under vacuum
* tinned wire leads
* box material is solvent resistant and flame retardant according to UL94V-0
* low attenuation
MKT pitch: 10...27,5 View larger

MKT RM15 630V 0,047µF

28004 MKT RM15 630V 0,047µF R60PI2470AA30K R60PI2470AA30K pitch: 10...27,5mm. * loose* tolerance: 10%* pitch: 10...27.5mm* dielectric polyester film* aluminium layer plates deposited by evaporation under vacuum* tinned wire leads* box material is solvent resistant and flame retardant according to UL94V-0* low attenuation

Data sheet

manufacturer
manufacturer's name R60PI2470AA30K
nominal voltage [V] 630
pitch [mm] 15
tolerance [%] 10
capacity [pF] 47000

Download

Data Sheet

2,39 €

Volume discounts

25 pcs. / 0,271 €

stock: 377
