DBU-3200-48

Mean Well charger series DBU-3200

Battery chargers for lead-acid/Li-ion batteries with 3200W, a universal input, a built-in OR-in FET, a programmable 3 stage charging curve, a built-in I²C interface, a PMBus protocol, a fan and a parallel function (up to 6400W / 1+1). These devices have a built-in active PFC function and are protected against overvoltage, battery undervoltage, overtemperature as well as short circuit. They have a programmable output voltage / output current and comply with EN55032 class B, EN55011 class B, EN55032 class A as well as EN55011 class A. We offer the following types of this Mean Well series: DBU-3200-24 and DBU-3200-48.

  • single output
  • output: 3200W
  • input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC
  • maximal input inrush current: 55A
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 1500V AC
  • operating temperature: -30 to +70°C
  • dimensions: 328,8x107x41mm
  • weight: 2760g
DBU-3200-48, Mean Well battery chargers, 3200W, for lead-acid and Li-ion batteries, parallel function, rack-mountable (1HE), DBU

DBU-3200-48

112255 DBU-3200-48 DBU-3200-48 4711287420950 Mean Well charger series DBU-3200. Battery chargers for lead-acid/Li-ion batteries with 3200W, a universal input, a built-in OR-in FET, a programmable 3 stage charging curve, a built-in I²C interface, a PMBus protocol, a fan and a parallel function (up to 6400W / 1+1). These devices have a built-in active PFC function and are protected against overvoltage, battery undervoltage, overtemperature as well as short circuit. They have a programmable output voltage / output current and comply with EN55032 class B, EN55011 class B, EN55032 class A as well as EN55011 class A. We offer the following types of this Mean Well series: DBU-3200-24 and DBU-3200-48. single output output: 3200W input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC maximal input inrush current: 55A withstand voltage I/P-O/P: 3000V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 1500V AC operating temperature: -30 to +70°C dimensions: 328,8x107x41mm weight: 2760g

Specifications

manufacturer
Manufacturer's name DBU-3200-48
GTIN 4711287420950
Charging voltage [V] 57,6
Float charge voltage [V] 55,2
Recommended accu capacity [Ah] 180...550
Efficiency [%] 94,5
Output current [A] 55
Data Sheet

Unit price

535,59 €

Stock: 59
Further delivery:
CW 32/2024
