DETN01N-12N

Mean Well DC/DC converter series DETN01-N

Unregulated DC/DC converters in an SMD housing with 1W and an input voltage ratio of 1:1. These devices are suitable for direct PCB mounting and are protected against short circuit. They are inexpensive, efficient and comply with EN55032. We offer the following types of this Mean Well series: DETN01L-05N, DETN01L-12N, DETN01L-15N, DETN01M-05N, DETN01M-12N, DETN01M-15N, DETN01N-05N, DETN01N-12N and DETN01N-15N.

  • dual output
  • output: 1W
  • output voltage tolerance: ±5%
  • maximal ripple and noise: 100mVpp
  • withstand voltage: 3000V DC
  • operating temperature: -40 to +100°C
  • weight: 1,2g
DETN01N-12N, Mean Well DC/DC converters, 1W, SMD, DETN01-N series

DETN01N-12N

241392 DETN01N-12N DETN01N-12N 4711287471228 Mean Well DC/DC converter series DETN01-N. Unregulated DC/DC converters in an SMD housing with 1W and an input voltage ratio of 1:1. These devices are suitable for direct PCB mounting and are protected against short circuit. They are inexpensive, efficient and comply with EN55032. We offer the following types of this Mean Well series: DETN01L-05N, DETN01L-12N, DETN01L-15N, DETN01M-05N, DETN01M-12N, DETN01M-15N, DETN01N-05N, DETN01N-12N and DETN01N-15N. dual output output: 1W output voltage tolerance: ±5% maximal ripple and noise: 100mVpp withstand voltage: 3000V DC operating temperature: -40 to +100°C weight: 1,2g

Specifications

manufacturer
Manufacturer's name DETN01N-12N
GTIN 4711287471228
Output voltage [V] ±12
Input voltage range [V] 21,6...26,4
Efficiency [%] 82
Output current [A] ±0,042
Data Sheet

Unit price

4,89 €

Volume discounts

Quantity Unit price
50 + 4,39 €

Stock: 32
Further delivery:
CW 42/2024
