LDC-35DA

Mean Well LED driver series LDC-35

LED drivers in an aluminium housing with a universal input, a constant power and 35W. These flickerfree devices are protected against overload (auto recovery), short circuit as well as overvoltage and comply with EN61000-3-2, class C, EN55015, EN61347-1 as well as EN61347-2-13. They have a built-in active PFC function and are suitable for LED lighting applications. We offer the following types of this Mean Well series: LDC-35, LDC-35B (with a 3 in 1 dimming function [0 to 10V DC, 10V PWM, potentiometer]) and LDC-35DA (with a DALI interface / push dimming).

  • single output
  • output: 35W
  • input voltage: 180 to 295V AC (47 to 63Hz)
  • maximal input inrush current: 30A
  • no-load power: <0,5W
  • withstand voltage I/P-O/P: 3750V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 1500V AC
  • operating temperature: -25 to +80°C
  • dimensions: 208x30x21mm
  • weight: 220g
Mean Well LDC-35 series

LDC-35DA

111894 LDC-35DA LDC-35DA 4711287456652 Mean Well LED driver series LDC-35. LED drivers in an aluminium housing with a universal input, a constant power and 35W. These flickerfree devices are protected against overload (auto recovery), short circuit as well as overvoltage and comply with EN61000-3-2, class C, EN55015, EN61347-1 as well as EN61347-2-13. They have a built-in active PFC function and are suitable for LED lighting applications. We offer the following types of this Mean Well series: LDC-35, LDC-35B (with a 3 in 1 dimming function [0 to 10V DC, 10V PWM, potentiometer]) and LDC-35DA (with a DALI interface / push dimming). single output output: 35W input voltage: 180 to 295V AC (47 to 63Hz) maximal input inrush current: 30A no-load power: &lt;0,5W withstand voltage I/P-O/P: 3750V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 1500V AC operating temperature: -25 to +80°C dimensions: 208x30x21mm weight: 220g

Specifications

manufacturer
Manufacturer's name LDC-35DA
GTIN 4711287456652
Output current range [mA] 625...1000
Efficiency [%] 88
Output power [W] 35
Ripple & noise [%] 3
Output voltage range [V] 27...65
Data Sheet

Unit price

28,79 €

Volume discounts

Quantity Unit price
50 + 27,09 €

Stock: 55
Further delivery:
CW 05/2026
