SCW12C-12

Mean Well DC/DC converter series SCW12 and DCW12

DC/DC converters in a DIL24 housing with 12W, a regulated output voltage, a remote ON/OFF control, a built-in EMI filter and an input voltage ratio of 2:1. These devices are suitable for PCB mounting and are protected against overload as well as short circuit. They have a galvanic isolation of input/output and comply with EN55032 class A. We offer various types of this Mean Well series.

  • single (SCW12_) or dual output (DCW12_)
  • output: 12W
  • overload protection: 110 to 180%
  • withstand voltage: 1500V DC
  • operating temperature: -40 to +71°C
  • weight: 18,5g
SCW12C-12, Mean Well DC/DC converters, 12W, DIL 24 housing, SCW12 and DCW12 series

SCW12C-12

32319 SCW12C-12 SCW12C-12 4711287475202 Mean Well DC/DC converter series SCW12 and DCW12. DC/DC converters in a DIL24 housing with 12W, a regulated output voltage, a remote ON/OFF control, a built-in EMI filter and an input voltage ratio of 2:1. These devices are suitable for PCB mounting and are protected against overload as well as short circuit. They have a galvanic isolation of input/output and comply with EN55032 class A. We offer various types of this Mean Well series. single (SCW12_) or dual output (DCW12_) output: 12W overload protection: 110 to 180% withstand voltage: 1500V DC operating temperature: -40 to +71°C weight: 18,5g

Specifications

manufacturer
Manufacturer's name SCW12C-12
GTIN 4711287475202
Case DIL 24 case
Input [V DC] 36...72
Output current range [mA] 200..1000
Output [V] 12
Efficiency [%] 83
Ripple [mV] 60
Data Sheet
