SCW20A-15

Mean Well DC/DC converter series SCW20 and DCW20

DC/DC converters in a DIL24 housing with 20W, a regulated output voltage, a remote ON/OFF control and an input voltage ratio of 2:1. These devices require no minimum load and are protected against overload as well as short circuit (continuous). They are suitable for PCB mounting and comply with EN55032 class A (without additional components). We offer various types of this Mean Well series.

  • single output (SCW20_) or dual output (DCW20_)
  • output: 20W
  • output voltage tolerance: ±2%
  • maximal ripple and noise: 80mVpp
  • withstand voltage: 1500V DC
  • operating temperature: -40 to +85°C
  • weight: 18,5g
SCW20A-15, Mean Well DC/DC converters, 20W, DIL24 housing, SCW20 and DCW20 series

SCW20A-15

111946 SCW20A-15 SCW20A-15 4711287475240 Mean Well DC/DC converter series SCW20 and DCW20. DC/DC converters in a DIL24 housing with 20W, a regulated output voltage, a remote ON/OFF control and an input voltage ratio of 2:1. These devices require no minimum load and are protected against overload as well as short circuit (continuous). They are suitable for PCB mounting and comply with EN55032 class A (without additional components). We offer various types of this Mean Well series. single output (SCW20_) or dual output (DCW20_) output: 20W output voltage tolerance: ±2% maximal ripple and noise: 80mVpp withstand voltage: 1500V DC operating temperature: -40 to +85°C weight: 18,5g

Specifications

manufacturer
Manufacturer's name SCW20A-15
GTIN 4711287475240
Output voltage [V] 15
Output current range [mA] 0...1333
Efficiency [%] 87
Ripple [mVp-p] 80
Input voltage [V DC] 9...18
Data Sheet

Unit price

20,59 €

Volume discounts

Quantity Unit price
50 + 19,19 €

Stock: 26
Further delivery:
CW 09/2026
