SLD-80-12

Mean Well LED driver series SLD-80

LED drivers in a plastic housing with a constant current, a universal input, a constant power or 80W. These devices are not dimmable, are suitable for LED lighting applications and comply with EN61347-1, EN61347-2-13, EN61000-3-2 class C as well as EN55015. They have a built-in active PFC function and are protected against overload (auto recovery), overvoltage, overtemperature as well as short circuit. We offer the follwing types of this Mean Well series: SLD-80-12, SLD-80-24 and SLD-80-56.

  • single output
  • output: 78,4 to 79,2W
  • input voltage: 110 to 305V AC (47 to 63Hz), 155 to 431V DC
  • maximal input inrush current: 50A
  • overcurrent protection (SLD-80-12/24): 95 to 108%
  • overload protection (SLD-80-56): 110 to 150%
  • withstand voltage (I/P-O/P): 3750V AC
  • operating temperature: -20 to +90°C
  • weight: 206g
SLD-80-12, Mean Well LED switching power supplies, 80W, CV und CC mixed mode, constant power, SLD-80 series

SLD-80-12

123082 SLD-80-12 SLD-80-12 4711287457604 Mean Well LED driver series SLD-80. LED drivers in a plastic housing with a constant current, a universal input, a constant power or 80W. These devices are not dimmable, are suitable for LED lighting applications and comply with EN61347-1, EN61347-2-13, EN61000-3-2 class C as well as EN55015. They have a built-in active PFC function and are protected against overload (auto recovery), overvoltage, overtemperature as well as short circuit. We offer the follwing types of this Mean Well series: SLD-80-12, SLD-80-24 and SLD-80-56. single output output: 78,4 to 79,2W input voltage: 110 to 305V AC (47 to 63Hz), 155 to 431V DC maximal input inrush current: 50A overcurrent protection (SLD-80-12/24): 95 to 108% overload protection (SLD-80-56): 110 to 150% withstand voltage (I/P-O/P): 3750V AC operating temperature: -20 to +90°C weight: 206g

Specifications

manufacturer
Manufacturer's name SLD-80-12
GTIN 4711287457604
Efficiency [%] 90,5
Output current [A] 6,6
Output voltage tolerance: [%] 4
Output power [W] 79,2
Ripple [mVp-p] 150
Output voltage range [V] 8,4...12
Data Sheet

Unit price

20,19 €

Volume discounts

Quantity Unit price
50 + 18,99 €

Stock: 95
Next incoming goods:
CW 28/2024
200 units

Further delivery:
CW 33/2024
