DPA01W8-15

Mean Well DC/DC converters series SPA01W8 and DPA01W8

Regulated DC/DC converters in a SIP6 housing with 1W, as well as they are protected against overload and short circuit. These devices are available in a type with single output (SPA01W8-_) or with dual output (DPA01W8-_). We offer various types of this Mean Well series.

  • output: 1W
  • output volatage tolerance: ±2%
  • withstand voltage: 1500V DC
  • operating temperature: -40 to +95°C
  • dimensions: 17,4x7,75x11,1mm
  • weight: 3g
DPA01W8-15, Mean Well DC/DC converters, 1W, SIP6 housing, SPA01W8 and DPA01W8 series

DPA01W8-15

252735 DPA01W8-15 DPA01W8-15 Mean Well DC/DC converters series SPA01W8 and DPA01W8. Regulated DC/DC converters in a SIP6 housing with 1W, as well as they are protected against overload and short circuit. These devices are available in a type with single output (SPA01W8-_) or with dual output (DPA01W8-_). We offer various types of this Mean Well series. output: 1W output volatage tolerance: ±2% withstand voltage: 1500V DC operating temperature: -40 to +95°C dimensions: 17,4x7,75x11,1mm weight: 3g

Specifications

manufacturer
Manufacturer's name DPA01W8-15
Output voltage [V] ±15
Input voltage range [V] 9...75
Efficiency [%] 77
Output current [A] ±0,033
Output power [W] 1
Data Sheet

Unit price

6,89 €

Volume discounts

Quantity Unit price
50 + 6,19 €

Stock: 28
Further delivery:
CW 05/2026
