> Power supplies>Power supplies>Surge protection devices>Mean Well surge protection devices (SPD), IP67, SPD-10-320S series>SPD-10-320S

Manufacturers

SPD-10-320S

Mean Well surge protection device series SPD-10-320S

Type 2+3 surge protectors (SPD) in a compact plastic housing (IP67) with an LED status display for protection class I devices. These devices are protected against overvoltages as well as earth-bound potential increases and are particularly suitable for final circuits (e.g. LED lighting). They comply with EN/IEC 61643-11 and should be mounted as close as possible to the device to be protected. We offer the type SPD-10-320S of this Mean Well series.

  • operating voltage: 120 to 320V AC (50/60Hz)
  • maximal continous current: 5A
  • protected phases: 1
  • maximal leakage current: 10kA
  • protection level L-N: 1200V
  • protection level L-G/PE: 1500V
  • protection level N-G/PE: 1500V
  • termination: wire
  • operating temperature: -40 to +70°C
SPD-10-320S, Mean Well AC surge protection SPD, IP67, SPD-10-320S series

SPD-10-320S

123899 SPD-10-320S SPD-10-320S 4711287464114 Mean Well surge protection device series SPD-10-320S. Type 2+3 surge protectors (SPD) in a compact plastic housing (IP67) with an LED status display for protection class I devices. These devices are protected against overvoltages as well as earth-bound potential increases and are particularly suitable for final circuits (e.g. LED lighting). They comply with EN/IEC 61643-11 and should be mounted as close as possible to the device to be protected. We offer the type SPD-10-320S of this Mean Well series. operating voltage: 120 to 320V AC (50/60Hz) maximal continous current: 5A protected phases: 1 maximal leakage current: 10kA protection level L-N: 1200V protection level L-G/PE: 1500V protection level N-G/PE: 1500V termination: wire operating temperature: -40 to +70°C

This product is no longer in stock

Specifications

manufacturer
Manufacturer's name SPD-10-320S
GTIN 4711287464114
Data Sheet

Unit price

8,39 €

Volume discounts

Quantity Unit price
50 + 7,89 €

Stock: 0
