SPWM-150-24DA2Q

Mean Well LED drivers series SPWM-150

LED drivers in a plastic housing universal input, 150W, a PWM style output, resp. a Dali-2 Push Dimm (SPWM-150-_DA2, SPWM-150-_DA2Q), and a 3 in 1 dimming function (0 to 10V DC, 10V PWM signal and resistance). We offer the following types of this Mean Well series: SPWM-150-12,  SPWM-150-12DA2, SPWM-150-12DA2Q, SPWM-150-24, SPWM-150-24DA2, and SPWM-150-24DA2Q.

  • single output
  • output: 150 to 151,2W
  • input voltage: 100 to 305V AC (47 to 63Hz), 156 to 410V DC
  • maximal inrush current: 55A
  • leakage current: <0,5W
  • operating temperature: -20 to +80°C
  • dimensions: 340x38x28,5mm
  • weight: 400g
SPWM-150-24DA2Q, Mean Well LED drivers, 150W, SPWM-150 series

SPWM-150-24DA2Q

256223 SPWM-150-24DA2Q SPWM-150-24DA2Q Mean Well LED drivers series SPWM-150. LED drivers in a plastic housing universal input, 150W, a PWM style output, resp. a Dali-2 Push Dimm (SPWM-150-_DA2, SPWM-150-_DA2Q), and a 3 in 1 dimming function (0 to 10V DC, 10V PWM signal and resistance). We offer the following types of this Mean Well series: SPWM-150-12,  SPWM-150-12DA2, SPWM-150-12DA2Q, SPWM-150-24, SPWM-150-24DA2, and SPWM-150-24DA2Q. single output output: 150 to 151,2W input voltage: 100 to 305V AC (47 to 63Hz), 156 to 410V DC maximal inrush current: 55A leakage current: &lt;0,5W operating temperature: -20 to +80°C dimensions: 340x38x28,5mm weight: 400g

Specifications

manufacturer
Manufacturer's name SPWM-150-24DA2Q
Output voltage [V] 24
Efficiency [%] 92
Output current [A] 6,3
Data Sheet

Unit price

42,19 €

Volume discounts

Quantity Unit price
50 + 41,29 €

Stock: 0
Further delivery:
CW 47/2026
