XLC-40-H-KN

Mean Well LED power supplies series XLC-40-KN

LED power supplies in a plastic case with 40W, a constant power, and a low no-load power (<0,5W). These devices are suitable for LED lighting applications, have a adjustable output current and comply with EN61347-1, EN61347-2-13, and EN55015. We offer the following types of this Mean Well series: XLC-40-H-KN and XLC-40-H-KNS.

  • power: 40W
  • input voltage range: 100 to 305V AC (47 to 63Hz), 141 to 400V DC
  • maximal inrush current: 10A
  • isolation voltage I/P-O/P: 3750V AC
  • operating temperature: -25 to +85°C
XLC-40-H-KN, Mean Well LED power supplies, 40W, constant power, XLC-40-KN series

XLC-40-H-KN

251316 XLC-40-H-KN XLC-40-H-KN Mean Well LED&nbsp;power supplies series XLC-40-KN. LED power supplies in a plastic case with 40W, a constant power, and a low no-load power (&lt;0,5W). These devices are suitable for LED lighting applications, have a adjustable output current and comply with EN61347-1, EN61347-2-13, and EN55015. We offer the following types of this Mean Well series: XLC-40-H-KN and XLC-40-H-KNS. power: 40W input voltage range: 100&nbsp;to 305V AC (47&nbsp;to 63Hz), 141&nbsp;to&nbsp;400V DC maximal&nbsp;inrush current: 10A isolation voltage&nbsp;I/P-O/P: 3750V AC operating temperature: -25&nbsp;to +85&deg;C

Specifications

Output voltage [V] 9...54
Efficiency [%] 88
Output current [A] 0,3...1,05
Data Sheet

Unit price

35,89 €

Stock: 7
Further delivery:
CW 05/2026
