XLC-60-48-MA

Mean Well LED power supplies series XLC-60-MA

LED power supplies in a plastic case with 60W, a constant power, and a low no-load power (<0,5W). These devices are suitable for LED lighting applications, have a adjustable output current and comply with EN61347-1, EN61347-2-13, and EN55015. We offer the following types of this Mean Well series: XLC-60-H-MA, XLC-60-H-MAS, XLC-60-12-MA, XLC-60-12-MAS, XLC-60-24-MA, XLC-60-24-MAS, XLC-60-48-MA, and XLC-60-48-MAS.

  • power: 60W
  • input voltage range: 100 to 305V AC (47 to 63Hz), 155 to 400V DC
  • maximal inrush current: 15A
  • isolation voltage I/P-O/P: 3750V AC
  • operating temperature: -25 to +90°C
XLC-60-48-MA, Mean Well LED power supplies, 60W, constant power/ constant voltage, adjustable, XLC-60-MA series

XLC-60-48-MA

251310 XLC-60-48-MA XLC-60-48-MA Mean Well LED power supplies series XLC-60-MA. LED power supplies in a plastic case with 60W, a constant power, and a low no-load power (&lt;0,5W). These devices are suitable for LED lighting applications, have a adjustable output current and comply with EN61347-1, EN61347-2-13, and EN55015. We offer the following types of this Mean Well series: XLC-60-H-MA, XLC-60-H-MAS, XLC-60-12-MA, XLC-60-12-MAS, XLC-60-24-MA, XLC-60-24-MAS, XLC-60-48-MA, and XLC-60-48-MAS. power: 60W input voltage range: 100 to 305V AC (47 to 63Hz), 155 to 400V DC maximal inrush current: 15A isolation voltage I/P-O/P: 3750V AC operating temperature: -25 to +90°C

Specifications

manufacturer
Manufacturer's name XLC-60-48-MA
Output voltage [V] 48
Efficiency [%] 88
Output current [A] 1,25
Data Sheet

Unit price

35,19 €

Volume discounts

Quantity Unit price
50 + 34,39 €

Stock: 30
Further delivery:
CW 05/2026
