MW MA06EU-L

Minwa plug-in power supply series MWM_EU

Plug-in switching power supplies with 7,2/12W, insulation class II, a Europlug, energy efficiency Level VI, a universal input and a low no-load power. These devices are suitable for various jack/coaxial plugs and are protected against overload, overvoltage as well as short circuit. They have a selectable output voltage and comply with EN61558-2-16 as well as EN61204-3. We offer the following types of this Minwa series: MW MA06EU-L, MW MA06EU-H and MW MB10E-H.

  • single output
  • output: 7,2 to 12W
  • input voltage: 100 to 240V AC (50/60Hz)
  • no-load power: <0,1W
  • operating temperature: 0 to +25°C
  • cable length: 1,8m
MWMA06EU-L, Minwa plug-in switching power supplies, 7,2 to 12W, MWMEU series

MW MA06EU-L

242241 MW MA06EU-L MWMA06EU-L MWMA06EU-L Minwa plug-in power supply series MWM_EU. Plug-in switching power supplies with 7,2/12W, insulation class II, a Europlug, energy efficiency Level VI, a universal input and a low no-load power. These devices are suitable for various jack/coaxial plugs and are protected against overload, overvoltage as well as short circuit. They have a selectable output voltage and comply with EN61558-2-16 as well as EN61204-3. We offer the following types of this Minwa series: MW MA06EU-L, MW MA06EU-H and MW MB10E-H. single output output: 7,2 to 12W input voltage: 100 to 240V AC (50/60Hz) no-load power: &lt;0,1W operating temperature: 0 to +25°C cable length: 1,8m

Specifications

manufacturer
Manufacturer's name MWMA06EU-L
Output voltage [V] 3/4,5/5/6/7,5/9/12
Efficiency [%] 69,64/72,81/...
Output current [A] 1/1/1/1/0,9/...
Output power [W] 7,2
Data Sheet

Unit price

6,89 €

Stock: 0
Next incoming goods:
CW 31/2024
1950 units

Further delivery:
CW 39/2024
