A12131121000

Molveno rocker switch series A1

Rocker switches with a maximal operating voltage of 250V DC and a maximal switching current of 10A for 13 x 19mm panel cut-outs. These 1-pole switches with a 4,8 x 0,8mm connector are suited for a maximal ambient temperature of 125°C. They are in compliance with the flammability class UL 94 V2 and have a contact gap of 3mm. We offer the type A11131100000 without an imprint, the type A11131121000 with a white imprint as well as the type A12131121000 with a solder terminal and the protective cap A1CAP for this series.


A12131121000

A12131121000

244154 A12131121000 A12131121000 Molveno rocker switch series A1. Rocker switches with a maximal operating voltage of 250V DC and a maximal switching current of 10A for 13 x 19mm panel cut-outs. These 1-pole switches with a 4,8 x 0,8mm connector are suited for a maximal ambient temperature of 125°C. They are in compliance with the flammability class UL 94 V2 and have a contact gap of 3mm. We offer the type A11131100000 without an imprint, the type A11131121000 with a white imprint as well as the type A12131121000 with a solder terminal and the protective cap A1CAP for this series.

Specifications

manufacturer
Manufacturer's name A12131121000
Switch positions 1xA-E
Case colour black
Rocker black
Rocker imprint I/O
Switching current [A] 10
Panel cut-out [mm] 13x19
Data Sheet

Unit price

0,574 €

Stock: 930
Further delivery:
CW 32/2024

Minimum order quantity 10 units or
multiples of 10.
