098-3-040-0-NFX-YT0

MPE Garry SMD socket strip series 098

  • single and double row socket strips in an angled design
  • suitable for PCB mounting
  • with a gold-plated contact surface
  • insulation shell is made of thermoplastic (UL94V-0)
  • fit for 0,64x0,64mm square pins
  • rated current: 3A

098-3-040-0-NFX-YT0

135413 098-3-040-0-NFX-YT0 098-3-040-0-NFX-YT0 MPE Garry SMD socket strip series 098. single and double row socket strips in an angled design suitable for PCB mounting  with a gold-plated contact surface insulation shell is made of thermoplastic (UL94V-0) fit for 0,64x0,64mm square pins rated current: 3A

Specifications

manufacturer
Manufacturer's name 098-3-040-0-...
Design angled
Number of poles 2x20
Height [mm] 3,7
Data Sheet

Unit price

2,29 €

Stock: 520
Further delivery:
CW 40/2024

Minimum order quantity 1 to 4 units or multiples of 12 plus 0 to 4 .
