DEP 16201-Y

OLED dot matrix modules

• dot matrix modules with 2 lines and 16 characters
• high contrast OLED display
• characters: yellow
• by Display Electronic
• operating lifetime: upt to 100.000h (min 120cd/m²)
• controller driver HD44780 compatible resp. SSD1311
• 1/16 duty cycle
• interface for I²C/SPI, 4- or 8-bit data bus
• supply voltage: 5V
• operating temperature range: -40 to +80°C

DEP 16201-Y

106203 DEP 16201-Y DEP16201-Y DEP16201-Y OLED dot matrix modules. • dot matrix modules with 2 lines and 16 characters• high contrast OLED display• characters: yellow• by Display Electronic• operating lifetime: upt to 100.000h (min 120cd/m²)• controller driver HD44780 compatible resp. SSD1311• 1/16 duty cycle• interface for I²C/SPI, 4- or 8-bit data bus• supply voltage: 5V• operating temperature range: -40 to +80°C


Manufacturer's name DEP16201-Y
Pixel size [mm] 2,95x5,55
Background black
Illumination yellow
Field of view [mm] 66x16
Dimensions [mm] 80x36x6,4
Data Sheet

Unit price

24,59 €

Stock: 110
