> Passive elements>Capacitors>Electrolytic capacitors>Panasonic electrolytic capacitors, radial, 105°C, low ESR, EE series>EEUEE2G680

Manufacturers

EEUEE2G680

Panasonic electrolytic capacitor series EE

  • aluminium electrolytic capacitors
  • with a high ripple current and a service life of 8000 to 10000h at 105°C
  • operating temperature: -25 to +105°C
  • capacitance tolerance: ±20%
  • bulk
EEUEE2G680, Panasonic electrolytic capacitors, radial, 105°C, low ESR, EE series

EEUEE2G680

36911 EEUEE2G680 EEUEE2G680 Panasonic electrolytic capacitor series EE. aluminium electrolytic capacitors  with a high ripple current and a service life of 8000 to 10000h at 105°C operating temperature: -25 to +105°C capacitance tolerance: ±20% bulk

Specifications

manufacturer
Manufacturer's name EEUEE2G680
Ripple Current (105°C, 100kHz) [mA] 1470
Diameter [mm] 18
Nominal voltage [V] 400
Capacity [µF] 68
Pitch [mm] 7,5
Length [mm] 25
Data Sheet

Unit price

2,09 €

Stock: 1880
Further delivery:
CW 43/2024

Minimum order quantity 10 units or
multiples of 10.
