EEUFR1V181

Panasonic electrolytic capacitor series FR

Aluminium eletrolytic capacitors in a radial type and with a service life of 5000 to 10 000h at 105°C. We offer various types of this Panasonic series.

  • operating temperature: -40 to +105°C
  • capacitance tolerance: ±20%
  • bulk and taped (EEUFR_B)
EEUFR1V181, Panasonic electrolytic capacitors, radial, 105°C, low ESR, FR series

EEUFR1V181

37009 EEUFR1V181 EEUFR1V181 Panasonic electrolytic capacitor series FR. Aluminium eletrolytic capacitors in a radial type and with a service life of 5000 to 10 000h at 105°C. We offer various types of this Panasonic series. operating temperature: -40 to +105°C capacitance tolerance: ±20% bulk and taped (EEUFR_B)

Specifications

manufacturer
Manufacturer's name EEUFR1V181
Design loose
Ripple Current (105°C, 100kHz) [mA] 950
Diameter [mm] 8
Nominal voltage [V] 35
Capacity [µF] 180
Pitch [mm] 3,5
Length [mm] 11,5
Data Sheet

Unit price

0,176 €

Stock: 6846
Further delivery:
CW 04/2027

Minimum order quantity 1 to 46 units or multiples of 50 plus 0 to 46 .
