> Passive elements>Capacitors>Electrolytic capacitors>Panasonic electrolytic capacitors, radial, 105°C, low ESR, FR series>EEUFR1E101

Manufacturers

EEUFR1E101

Panasonic electrolytic capacitor series FR

Aluminium eletrolytic capacitors in a radial type and with a service life of 5000 to 10 000h at 105°C. We offer various types of this Panasonic series.

  • operating temperature: -40 to +105°C
  • capacitance tolerance: ±20%
  • bulk and taped (EEUFR_B)
EEUFR1E101, Panasonic electrolytic capacitors, radial, 105°C, low ESR, FR series

EEUFR1E101

39982 EEUFR1E101 EEUFR1E101 Panasonic electrolytic capacitor series FR. Aluminium eletrolytic capacitors in a radial type and with a service life of 5000 to 10 000h at 105°C. We offer various types of this Panasonic series. operating temperature: -40 to +105°C capacitance tolerance: ±20% bulk and taped (EEUFR_B)

Specifications

manufacturer
Manufacturer's name EEUFR1E101
Design loose
Ripple Current (105°C, 100kHz) [mA] 455
Diameter [mm] 6,3
Nominal voltage [V] 25
Capacity [µF] 100
Pitch [mm] 2,5
Length [mm] 11,2
Data Sheet

Unit price

0,081 €

Stock: 5350
Next incoming goods:
CW 30/2026
25000 units

Further delivery:
CW 04/2027

Minimum order quantity 50 units or
multiples of 50.
