EEUFS2A271S

Panasonic capacitor series FS

  • radial type aluminium electrolytic capacitors
  • with a low ESR and a compact size
  • operating temperature: -40 to +105°C
  • service life: 5000 to 10 000h (at 105°C)
  • capacitance tolerance: ±20%
  • rated voltage: 6,3 to 100V DC
  • bulk and taped (EEUFS_B/EEUFS_H)
EEUFS2A271S, Panasonic electrolytic capacitors, radial, 105°C, low ESR, FS series

EEUFS2A271S

236899 EEUFS2A271S EEUFS2A271S Panasonic capacitor series FS. radial type aluminium electrolytic capacitors with a low ESR and a compact size operating temperature: -40 to +105°C service life: 5000 to 10 000h (at 105°C) capacitance tolerance: ±20% rated voltage: 6,3 to 100V DC bulk and taped (EEUFS_B/EEUFS_H)

Specifications

manufacturer
Manufacturer's name EEUFS2A271S
Nominal voltage [V DC] 100
Capacity [µF] 270
Pitch [mm] 7,5
Dimensions [mm] 16x20
Data Sheet

Unit price

1,25 €

Stock: 50
Next incoming goods:
CW 30/2024
200 units

Further delivery:
CW 44/2024

Minimum order quantity 50 units or
multiples of 50.
