EEEHA1J220UP

Panasonic electrolytic capacitor series HA

SMD electrolytic capacitors in high temperature types, comply with AEC-Q200. We offer various types of this Panasonic series.

  • operating temperature: -40 to +105°C
  • service life (at 105°C): 1000h
  • rated voltage: 6,3 to 100V DC
  • capacitance tolerance: ±20%
  • taped
EEEHA1J220UP, Panasonic electrolytic capacitors, SMD, 105°C, 1000h, HA series

EEEHA1J220UP

110765 EEEHA1J220UP EEEHA1J220UP Panasonic electrolytic capacitor series HA. SMD electrolytic capacitors in high temperature types, comply with AEC-Q200. We offer various types of this Panasonic series. operating temperature: -40 to +105°C service life (at 105°C): 1000h rated voltage: 6,3 to 100V DC capacitance tolerance: ±20% taped

Specifications

manufacturer
Manufacturer's name EEEHA1J220UP
Design E
Reverse current [mA] 25
Nominal voltage [V DC] 63
Rated capacitance [µF] 22
Loss factor at 120Hz, 20°C 0,18
Diameter [mm] 8
Length [mm] 6,2
Data Sheet

Unit price

0,186 €

Stock: 1000
Further delivery:
CW 19/2026

Minimum order quantity 100 units or
multiples of 100.
