> Passive elements>Capacitors>Electrolytic capacitors>Panasonic solid capacitors, radial, 125°C, OS-CON, SEF series>16SEF560M

Manufacturers

16SEF560M

Panasonic solid capacitor series SEF

  • halogen free radial OS-CON polymer aluminium solid capacitors
  • highly conductive polymers provide an excellent noise reduction capability and an ideal frequency characteristic
  • with a long service life (1000h at +125°C), a high reliability and a high heat resistance (-55 to +125°C)
  • capacitance tolerance: ±20%
  • taped
16SEF560M, Panasonic solid capacitors, radial, 125°C, OS-CON, SEF series

16SEF560M

122125 16SEF560M 16SEF560M Panasonic solid capacitor series SEF. halogen free radial OS-CON polymer aluminium solid capacitors  highly conductive polymers provide an excellent noise reduction capability and an ideal frequency characteristic with a long service life (1000h at +125°C), a high reliability and a high heat resistance (-55 to +125°C) capacitance tolerance: ±20% taped

Specifications

manufacturer
Manufacturer's name 16SEF560M
Nominal voltage [V DC] 16
Diameter [mm] 8
Capacity [µF] 560
Pitch [mm] 3,5
Length [mm] 12
Data Sheet

Unit price

0,911 €

Stock: 300
Further delivery:
CW 40/2024

Minimum order quantity 25 units or
multiples of 25.
