20SEF120M

Panasonic solid capacitor series SEF

  • halogen free radial OS-CON polymer aluminium solid capacitors
  • highly conductive polymers provide an excellent noise reduction capability and an ideal frequency characteristic
  • with a long service life (1000h at +125°C), a high reliability and a high heat resistance (-55 to +125°C)
  • capacitance tolerance: ±20%
  • taped
20SEF120M, Panasonic solid capacitors, radial, 125°C, OS-CON, SEF series

20SEF120M

122127 20SEF120M 20SEF120M Panasonic solid capacitor series SEF. halogen free radial OS-CON polymer aluminium solid capacitors  highly conductive polymers provide an excellent noise reduction capability and an ideal frequency characteristic with a long service life (1000h at +125°C), a high reliability and a high heat resistance (-55 to +125°C) capacitance tolerance: ±20% taped

Specifications

manufacturer
Manufacturer's name 20SEF120M
Nominal voltage [V DC] 20
Diameter [mm] 6,3
Capacity [µF] 120
Pitch [mm] 2,5
Length [mm] 6
Data Sheet

Unit price

0,635 €

Stock: 1450
Further delivery:
CW 41/2024

Minimum order quantity 25 units or
multiples of 25.
