25SVPK33M

Panasonic electrolytic capacitor series SVPK

Surface mount OS-CON electrolytic capacitors with a long service lifetime, a high reliability and a high heat resistance. These components use aluminum and a highly conductive polymer to achieve an excellent noise reduction capability and an ideal frequency characteristic.

  • capacitance tolerance: ±20%
  • operating temperature: -55 to +125°C
  • operating life (at 125°C): 1000h
  • taped
25SVPK33M, Panasonic electrolytic capacitors, SMD, 125°C, polymer hybrid aluminium, OS-CON, SVPK series

25SVPK33M

119465 25SVPK33M 25SVPK33M Panasonic electrolytic capacitor series SVPK. Surface mount OS-CON electrolytic capacitors with a long service lifetime, a high reliability and a high heat resistance. These components use aluminum and a highly conductive polymer to achieve an excellent noise reduction capability and an ideal frequency characteristic. capacitance tolerance: ±20%operating temperature: -55 to +125°Coperating life (at 125°C): 1000htaped

Specifications

manufacturer
Manufacturer's name 25SVPK33M
Nominal voltage [V DC] 25
Capacity [µF] 33
Data Sheet

Unit price

0,405 €

Stock: 1500
Further delivery:
CW 41/2024

Minimum order quantity 25 units or
multiples of 25.
