1241.3005

Schurter Piezo pushbutton series PSE NO

Vandalproof Piezo push button switches with 1x normally open contact and a long service life. These momentary switches have an excellent quality and are IP69K rated. They are suitale for high-pressure cleaners, are sea-water resistant and have a pin, plug-in or stranded wire connection. We offer the following types of this Schurter series: 1241.2411.3, 1241.2411.8, 1241.3005, 1241.3006, 2141.3008, 1241.3258 and 1241.3011.

  • contact: 1x Schließer
  • panel cut-out: Ø20 to 26mm
  • maximal switching voltage: 42V AC / 60V DC
  • maximal switching current: 100mA
  • maximal switching capacity: 1W
  • operating temperature: -40 to +85°C
Schurter piezo push button switches, for Ø20 to 26mm panel cut-out, 1 normally open contact, vandal-proof, PSE NO series

1241.3005

32614 1241.3005 1241.3005 Schurter Piezo pushbutton series PSE NO. Vandalproof Piezo push button switches with 1x normally open contact and a long service life. These momentary switches have an excellent quality and are IP69K rated. They are suitale for high-pressure cleaners, are sea-water resistant and have a pin, plug-in or stranded wire connection. We offer the following types of this Schurter series: 1241.2411.3, 1241.2411.8, 1241.3005, 1241.3006, 2141.3008, 1241.3258 and 1241.3011. contact: 1x Schließer panel cut-out: Ø20 to 26mm maximal switching voltage: 42V AC / 60V DC maximal switching current: 100mA maximal switching capacity: 1W operating temperature: -40 to +85°C

Specifications

manufacturer
Manufacturer's name 1241.3005
Case colour red
Connections pins
Illumination unlighted
Switching current [A] 0,1
Panel cut-out [mm] Ø 26
Data Sheet

Unit price

20,89 €

Stock: 23
Next incoming goods:
CW 03/2026
20 units

Further delivery:
CW 07/2026
