> Passive elements>Fuses>Circuit breakers>Schurter Combi Circuit Breaker, with rocker switch, IP40, TA35 und TA36 series>3-150-707

Manufacturers

3-150-707

Schurter Combi Circuit Breaker series TA35 und TA36

Unilluminated 2-pole combi circuit breaker with rocker switch. These circuit breakers are thermal-magnetic and are suitable for front panel mounting, as well as snap-on mounting. We offer the following types of this Schuter series: 3-150-705, 3-150-706, 3-150-707, 3-150-708, 3-150-709, 3-150-710, 3-150-711, 3-150-712, 3-150-713, and 3-150-714.

  • rated voltage: 60V DC, 240V AC
  • termination style: flat plug 6.3x0.8mm
  • operating temperature: -30 to 60°C
3-150-707, Schurter Combi Circuit Breaker, with rocker switch, IP40, TA35 und TA36 series

3-150-707

253423 3-150-707 3-150-707 Schurter Combi Circuit Breaker series TA35 und TA36. Unilluminated 2-pole combi circuit breaker with rocker switch. These circuit breakers are thermal-magnetic and are suitable for front panel mounting, as well as snap-on mounting. We offer the following types of this Schuter series: 3-150-705, 3-150-706, 3-150-707, 3-150-708, 3-150-709, 3-150-710, 3-150-711, 3-150-712, 3-150-713, and 3-150-714. rated voltage: 60V DC, 240V AC termination style: flat plug 6.3x0.8mm operating temperature: -30 to 60°C

Specifications

manufacturer
Manufacturer's name 3-150-707
Colour green
Rated current [A] 16
Data Sheet

Unit price

29,69 €

Stock: 10
Further delivery:
CW 07/2026
