SPS 8034 Ni / RT

Schützinger safety test probe series SPS 8034 Ni

Safety test probes with 5A and a inline safety socket for terminal connection. They have a flexible tip for measuring in inaccessible places. We offer the following types of this Schützinger series: SPS 8034 Ni / RT and SPS 8034 Ni / SW.

  • contact tip: steel (VA)
  • insulation: PA 6.6 (polyamid)
  • transition resistance : 20 mΩ
  • rated voltage: 1000V (CAT II)
  • rated current: 5A
  • operating temperature: -25 to 80°C
SPS 8034 NI / RT, Schützinger safety test probe, 5A, SPS 8034 Ni series

SPS 8034 Ni / RT

253762 SPS 8034 Ni / RT SPS 8034 NI / RT SPS 8034 NI / RT Schützinger safety test probe series SPS 8034 Ni . Safety test probes with 5A and a inline safety socket for terminal connection. They have a flexible tip for measuring in inaccessible places. We offer the following types of this Schützinger series: SPS 8034 Ni / RT and SPS 8034 Ni / SW. contact tip: steel (VA) insulation: PA 6.6 (polyamid) transition resistance : 20 mΩ rated voltage: 1000V (CAT II) rated current: 5A operating temperature: -25 to 80°C

Specifications

manufacturer
Manufacturer's name SPS 8034 NI / RT
Colour red
Data Sheet

Unit price

5,29 €

Stock: 6
Further delivery:
CW 51/2025
