KS100 d 0,7mm 250g

lead-free soldering wires KS 100 TSC Flowtin by Stannol

* melting point: 217°C
* flux type (IEC 61190-1-3 REL0): 1.2.3.B
* flux content (EN 12224): 3%
* corrosive effects (DIN 8516): none
* alloy (FLOWTIN TSC): Sn95Ag4Cu1/713
* flux core: 1 core
* diameter: 0.7mm
* by Stannol


* halide-free activated
* developed to cope with the higher process temperatures at lead-free soldering
* very low spitting of flux
* with micro doted alloys for the low solder tip consumption
* high activity, good spread and high residue reliability
* flux residues - can be left on the PCB
* hand and robot soldering
* electronic and electrical industry

KS100 View larger

KS100 d 0,7mm 250g

27752 KS100 d 0,7mm 250g 574612 574612 lead-free soldering wires KS 100 TSC Flowtin by Stannol. * melting point: 217°C* flux type (IEC 61190-1-3 REL0): 1.2.3.B* flux content (EN 12224): 3%* corrosive effects (DIN 8516): none* alloy (FLOWTIN TSC): Sn95Ag4Cu1/713* flux core: 1 core* diameter: 0.7mm* by Stannol * halide-free activated* developed to cope with the higher process temperatures at lead-free soldering* very low spitting of flux* with micro doted alloys for the low solder tip consumption* high activity, good spread and high residue reliability* flux residues - can be left on the PCB* hand and robot soldering* electronic and electrical industry

Data sheet

manufacturer
manufacturer's name 574612

Download

Data Sheet

26,09 €

stock: 18
