STGP 20 V 60 DF

STMicroelectronics IGBT series STGF and STGP

Insulated-gate bipolar transistors (IGBTs) in a TO220 housing and with PowerMESH™. We offer various types of this STMicroelectronics series.

TO220

STGP 20 V 60 DF

106976 STGP 20 V 60 DF STGP20V60DF STGP20V60DF STMicroelectronics IGBT series STGF and STGP. Insulated-gate bipolar transistors (IGBTs) in a TO220 housing and with PowerMESH™. We offer various types of this STMicroelectronics series.

Specifications

manufacturer
Manufacturer's name STGP20V60DF
Case TO220
Power dissipation [W] 167
Turn-on delay time [ns] 38
Max. collector-emitter breakdown voltage [V] 600
Min. gate threshold voltage [V] 5
Max. collector current, pulsed [A] 80
Turn-off delay time [ns] 149
Max. continuous collector current at TC = 25°C 40
Data Sheet

Unit price

1,64 €

Stock: 0
Further delivery:
CW 13/2026

Minimum order quantity 1.000 units or
multiples of 1.000.
