MF70151V1-1000U-A99

Sunon fan series ME and MF

DC fans with a vapo bearing system and 12V. These fans have a frame as well as an impeller made of thermoplastic PBT (UL94V-0) and a 4-pole brushless motor (MagLev). They are suitable for various applications and have a long service life. We offer the following types of this Sunon series: ME70151V1-000U-G99, ME70151V3-000U-A99, MF70151V1-1000U-A99, and MF70151V3-1000U-A99

  • rated voltage: 12V DC
  • dimensions: 70x70x15mm

MF70151V1-1000U-A99

MF70151V1-1000U-A99

252772 MF70151V1-1000U-A99 MF70151V1-1000U-A99 Sunon fan series ME and MF. DC fans with a vapo bearing system and 12V. These fans have a frame as well as an impeller made of thermoplastic PBT (UL94V-0) and a 4-pole brushless motor (MagLev). They are suitable for various applications and have a long service life. We offer the following types of this Sunon series: ME70151V1-000U-G99, ME70151V3-000U-A99, MF70151V1-1000U-A99, and MF70151V3-1000U-A99 rated voltage: 12V DC dimensions: 70x70x15mm

Specifications

manufacturer
Manufacturer's name MF70151V1-10...
Current [A] 0,074
Dimensions 70x70x15
Nominal voltage [V] 12
Electric power [W] 0,89
Noise [dBA] 30
Number of revolutions [U/min] 3.500
Data Sheet

Unit price

5,39 €

Stock: 0
Further delivery:
CW 21/2026
