containing lead

* halide-activated resin fluxes
* high activity, good spread and high residue reliability
* optimal wetting and spreading properties
* shiny solder joints with minimal flux residues
* flux residues - can be left on the PCB
* woldering o...

containing lead

* halide-activated resin fluxes
* high activity, good spread and high residue reliability
* optimal wetting and spreading properties
* shiny solder joints with minimal flux residues
* flux residues - can be left on the PCB
* woldering operations on transformers and soldering copper cables with large cross sections
* when a stronger flux is needed due to the high termal capacity of the components that require soldering
* hand and robot soldering
* electrotechnology
* melting range: 183...190°C
* flux type (IEC 61190-1-3 ROM1): 1.1.2.B
* flux content: 2.2%
* corrosive effects (DIN 8516): none
* alloy (ISO 9453:2006): S-Sn60Pb39Cu1
* flux core: 3 core

> More
