DEM 16216 FGH-PRGB

LCD dot matrix modules

• dot matrix modules with 2 lines and 16 characters
​• high contrast LCD-FSTN display
• LED backlight
• colour: red, green or blue selectable
​​
• characters: black
• by Display Elektronik
• interface for 4- or 8-Bit data bus
• supply voltage: 5V
• operating temperature range: -20 to +70°C


DEM 16216 FGH-PRGB View larger

DEM 16216 FGH-PRGB

8244 DEM 16216 FGH-PRGB DEM16216FGH-P(RGB) DEM16216FGH-P(RGB) LCD dot matrix modules. • dot matrix modules with 2 lines and 16 characters​• high contrast LCD-FSTN display• LED backlight• colour: red, green or blue selectable​​• characters: black• by Display Elektronik• interface for 4- or 8-Bit data bus• supply voltage: 5V• operating temperature range: -20 to +70°C

Data sheet

manufacturer
manufacturer's name DEM16216FGH-P(RGB)
dimensions [mm] 80x36x10,5
lines 2
characters 16
background RGB
illumination RGB
field of view [mm] 61x15,8

Download

Data Sheet

17,09 €

stock: 587
