Mean Well LED driver series LPF-25

LED drivers in a plastic housing (IP67) with a constant voltage, 25W and a universal input. These devices are protected against overload (auto recovery), short circuit as well as overvoltage, are suitable for LED lighting applications and have a built-in active PFC function. They comply with UL1310 class 2, EN61000-3-2, class C, EN55015, EN61347-1 as well as EN61347-2-13. We offer the following types of this Mean Well series: LPF-25-12, LPF-25-15, LPF-25-20, LPF-25-24, LPF-25-30, LPF-25-36, LPF-25-42, LPF-25-48 and LPF-25-54.

single output
output: 25 to 25,44W
input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
maximal input inrush current: 50A
withstand voltage I/P-O/P: 3750V AC
operating temperature: -35 to +70°C
dimensions: 148x40x32mm
weight: 360g

> More

Data Sheet
