Mean Well LED driver series HLG-150H

LED drivers in a metal housing (IP67) with a constant current, a 3 in 1 dimming function (1 to 10V DC, PWM, 100kOhm potentiometer) and 150W. These devices are protected against overload (auto recovery), short c...

Mean Well LED driver series HLG-150H

LED drivers in a metal housing (IP67) with a constant current, a 3 in 1 dimming function (1 to 10V DC, PWM, 100kOhm potentiometer) and 150W. These devices are protected against overload (auto recovery), short circuit, overtemperature as well as overvoltage and comply with EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 class C, EN61000-3-3 as well as EN61547. They have a built-in active PFC function and are suitable for LED lighting applications. We offer the following types of this Mean Well series: HLG-150H-12B, HLG-150H-15B, HLG-150H-20B, HLG-150H-24B, HLG-150H-30B, HLG-150H-36B, HLG-150H-42B, HLG-150H-48B and HLG-150H-54B.

  • single output
  • output: 150 to 153,6W
  • input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
  • maximal input inrush current: 65A
  • withstand voltage I/P-O/P: 3750V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 1500V AC
  • operating temperature: -40 to +90°C
  • dimensions: 228x68x38,8mm
  • weight: 1150g
> More
Data Sheet
Showing 1 - 9 of 9 products
  • Product Stock Unit price Volume discounts
  • Mean Well
    HLG-150H-12B
    39,19 €
    36542 HLG-150H-12B HLG-150H-12B
    39,19 €
    Quantity Unit price
    50 + 38,19 €
    Stock: 285
  • Mean Well
    HLG-150H-15B, Mean Well LED drivers, 150W, IP67, dimmable, HLG-150H_B series
    46,69 €
    135834 HLG-150H-15B HLG-150H-15B
    46,69 €
    Quantity Unit price
    50 + 45,19 €
    Stock: 5
  • Mean Well
    HLG-150H-20B, Mean Well LED drivers, 150W, IP67, CV and CC mixed mode, dimmable, HLG-150H series
    53,39 €
    244604 HLG-150H-20B HLG-150H-20B
    53,39 €
  • Mean Well
    HLG-150H-24B
    37,79 €
    36536 HLG-150H-24B HLG-150H-24B
    37,79 €
    Quantity Unit price
    50 + 36,89 €
    Stock: 834
  • Mean Well
    HLG-150H-30B, Mean Well LED drivers, 150W, IP67, CV and CC mixed mode, dimmable, HLG-150H series
    53,39 €
    244607 HLG-150H-30B HLG-150H-30B
    53,39 €
  • Mean Well
    HLG-150H-36B
    44,09 €
    41257 HLG-150H-36B HLG-150H-36B
    44,09 €
    Quantity Unit price
    50 + 42,69 €
    Stock: 8
  • Mean Well
    HLG-150H-42B, Mean Well LED drivers, 150W, IP67, dimmable, HLG-150H_B series
    46,69 €
    135837 HLG-150H-42B HLG-150H-42B
    46,69 €
    Quantity Unit price
    50 + 45,19 €
    Stock: 0
  • Mean Well
    HLG-150H-48B, Mean Well LED drivers, 150W, IP67, dimmable, HLG-150H_B series
    44,09 €
    135839 HLG-150H-48B HLG-150H-48B
    44,09 €
    Quantity Unit price
    50 + 42,69 €
    Stock: 47
  • Mean Well
    HLG-150H-54B, Mean Well LED drivers, 150W, IP67, dimmable, HLG-150H_B series
    46,69 €
    135841 HLG-150H-54B HLG-150H-54B
    46,69 €
    Quantity Unit price
    50 + 45,19 €
    Stock: 22
Showing 1 - 9 of 9 products
