Mean Well DIN rail power supply series DR-60

Switching power supplies with 60W, a universal input, insulation class II, an LED indicator for power on and screw terminals (touch guard). These devices are suitable for DIN rail mounting and are protected against overload (auto recovery), overvoltage as well as short circuit. They have a fanless design and comply with EN50178, EN55011, EN55032 class B, EN61000-3-2 as well as EN61000-3-3. We offer the following types of this Mean Well series: DR-60-12 and DR-60-15.

• single output
• output: 54 to 60W
• input voltage: 88 to 264V AC (47 to 63Hz), 124 to 370V DC
• maximal input inrush current: 36A
• output voltage adjustment: ±10%
• overload protection: 105 to 160%
• withstand voltage I/P-O/P: 3000V AC
• operating temperature: -20 to +60°C
• weight: 300g
